P1.86mm UHD TV Studio High Definition Video Wall Panel Digital Advertising Display Board Small Pitch Indoor Full Color LED Screen

Basic Info.

Model NO.	SY-P1.86-43S-I
Pixel Configuration	1R,1G,1B
Pixel Density	289050 Dots/M2
Scanning Mode	1/43 Scan
System Operating Platform	Win98/2000/Nt/XP
Display Type	LED Video Display
Application	Stage Performance, Advertising, Shopping Guide
IP Rating	IP43
Certification	CE, RoHS, CCC, FCC
Cabinet Size	640mm*480mm
Cabinet Material	Die Casting Aluminum
OEM	Yes
Ratio	16:9
Cabinet Weight	5.5kg Per Cabinet
Display Content	Video, Picture, Cartoon, Graphics, Texts.etc.
with Video Processor	Video, VGA, HDMI, DVI, SDI/HD-SDI/3G-SDI
Control System	Novastar, or Linsn, or Colorlight or as Required.
Control Mode	Synchronous Display with Control PC by DVI
Transport Package	Flight Case or Plywood Box
Specification	P1.86
Trademark	SENY
Origin	Shenzhen, Guangdong, China
HS Code	8528591090
Production Capacity	100000

Packaging & Delivery

Package Size 76.00cm * 71.00cm * 88.00cm Package Gross Weight 74.000kg

Product Description

P1.86mm UHD TV Studio High Definition Video Wall Panel Digital Advertising Display Board Small Pitch Indoor Full Color LED Screen

Application:

Applied to indoor places such as station, port, airport, meeting room, shopping mall, hotel, TV station etc. it uses as video and information display. Technical Parameter:

S/N	Item Name	Technical Parameter
LED Parameter
1	Item Name	LED Type	Wave Length	H/V Visual Angle
2	Red LED	SMD1515	620-625nm	140 º/120 º
3	Green LED	SMD1515	520-525nm	140 º/120 º
4	Blue LED	SMD1515	470-475nm	140 º/120 º
Module Parameter
1	Pixel Pitch	1.86mm
2	Pixel Configuration	1R1G1B
3	Module Resolution	172 x 86 pixels
4	Module Pixles	14792 pixels
5	Module Size	320mm x 160mm
Cabinet Parameter
1	Cabinet Size(W X H X D)	640mm x 480mm x 70mm
2	Cabinet Resolution(dot)	344 x 258 pixels
3	Module Quanity (pcs)	6pcs
4	Cabinet Pixels	88752 pixels
5	Pixel Density	289050 pixels/m2
6	Cabinet Type	Die Casting Aluminum, front maintenance
7	Cabinet Weight	5.5kg per cabinet
Whole Screen Parameter
1	Screen Brightness	800cd/m2
2	Driving Method	1/43 scan, constant current
3	Min. Viewing Distance	1 meter
4	Max. Power Consumption	≤650 W/m2
5	Ave. Power Consumption	≤200W/m2
6	Gray Level	16 bits
7	Frame Frequency	≥60Hz
8	Refresh Frequency	≥3840Hz
9	LED Life-span	≥100,000 hours
10	MTBF	≥5,000 hours
11	Discrete Blind Spot Rate	<1/10000
12	Continuous Blind Spot Rate	None
13	Blind Spot Rate	<1/10000
14	Protective Scale	For indoor use only
15	Screen Plainness	<±1mm
16	Power Supply Mode	AC220±10% 50Hz/AC110±10% 60Hz
17	Working Temperature	Temperature: 0 Celsius~+40 Celsius
18	Storage Temperature	Temperature:-30 Celsius~+50 Celsius
19	Humidity	Humidity:10%~90% RH
20	Control Mode	Synchronous display with control PC by DVI
21	Control System	Linsn, Novastar or Colorlight or as required.
22	Display Content	Video, picture, cartoon, graphics, texts.etc.
23	Interface	Standard Ethernet
24	Transmission Distance	Multi mode fiber <500m, single mode fiber <20km,internet cable <100m
25	With Video Processor	Video,VGA,HDMI,DVI,SDI/HD-SDI/3G-SDI

Cases:Production Process:Certification:Packaging and Shipping:Our Services:Pre-sales support:1. We offered technical advice to you before buying our products.2. Help you to choose suitable products within budget with most economy benefit.3. Design the framework structure to install our led products with technical drawing.4. We offered software customization for our your specific usage.After- sales service:1. We promise you more than two years warranty service!2.We provide free maintenance services including remote configuration, technical consultation, and trouble shooting for you.3. We promise a life time follow-up service for all the equipment supply by our company. These include continuously improve of system functions and upgrade of system software.4. We offered training to our customer who includes operating and maintenance of our products.FAQ:
